Legrand Fuse Catalogue
Name : Hanselec(hans.1976@hanselec.co.kr) Date : 2018-08-22 Hits : 2900
File : HRC catridge Fuse용.pdf
Fuse
Legrand's cylindrical fuse, which can be mounted on a fuse carrier, offers the best performance and safety for the proctection of electrical circuits in a compact and simple design.
IEC 60269-1, 2 Suitable for specifications
- General Purpose (gG Type)
  - 8.5x31.5 HRC (1~16A, 400V~)
  - 10x38 HRC (0.5 ~ 25A, 500V~)
  - 14x51 HRC (6 ~50A, 500V~)
-Motor Protection (aM Type)
  - 8.5x31.5 HRC (4~10A~)
  - 10x38 HRC (0.5 ~ 25A~)
  - 14x51 HRC (2 ~50A, 500V~(400V~))
